Lorry
Products of Seongbu Industry representing the domestic agricultural machinery market are safely and usefully used and we have made efforts to produce the best quality.
> Prooduct > Lorry

Lorry

Lorry
SB-3500Series
The unique sliding function of a working table in the country
Possessing many patents regarding agricultural vehicles for high-place works
SB-3500, SB-3510
MORE
SB-3500 Series Major Specification
▼ SB-3500
SB-3510 ▼
ItemDescriptionItemDescription
TypeSB-3500TypeSB-3510
Dimension(Length X Width X Height)1,873 x 1,000 x 1,194Dimension(Length X Width X Height)1,873 x 1,000 x 1,114
Size of Cargo Box1,480 x 1,060 x 250Size of Cargo Box1,480 x 1,060 x 250
Running Speed and Max. Load2.6km/h / 500kgRunning Speed and Max. Load2.6km/h / 500kg
Dumping Angle (˚)50 Dumping Angle (˚)50
Lifting Height (mm)1,400Lifting Height (mm)1,320
Length of Slider (mm)430Length of Slider (mm)No Slider Function
Features and Performance
Lorry
Functions of dumping & lifting
With both functions of dumping & lifting, it reduces labor and improves productivity.
SB-3500 Lifting Height 1,400mm
Whether to drive a function of dumping of a lorry
SB-3500
SERIES
SB-3500O
SB-3510O
Whether to drive a function of lifting of a lorry
SB-3500
SERIES
SB-3500O
SB-3510O
The unique sliding function of a working table &
the automatic straight running
With the unique sliding function of a working table, it considered convenience of an operator.
It increased work efficiency with a function of the automatic straight running.
A length of the extended working table of SB-3500 1,430mm
Whether to drive a function of the automatic straight running of a lorry
SB-3500
SERIES
SB-3500O
SB-3510O
Whether to drive a sliding function of a working table
SB-3500
SERIES
SB-3500O
SB-3510X
A video of product
Lorry
SB-3600Series
The unique sliding function of a working table in the country
Possessing many patents regarding agricultural vehicles for high-place works
SB-3500, SB-3510
MORE
SB-3600 Series Major Specification
▼ SB-3600ADL
▼ SB-3600AD
▼ SB-3600A
ItemDescriptionItemDescriptionItemDescription
TypeSB-3600ADLTypeSB-3600ADTypeSB-3600A
Dimension(Length X Width X Height)1,396×770×1,239Dimension(Length X Width X Height)1,396×770×1,164Dimension(Length X Width X Height)1,396×770×1,164
Size of Cargo Box (mm)1,100 × 550 × 200Size of Cargo Box (mm)1,100 × 550 × 200Size of Cargo Box (mm)1,100 × 550 × 200
Running Speed (km/h)2.6km/hRunning Speed (km/h)2.6km/hRunning Speed (km/h)2.6km/h
Max. Load (kg)250Max. Load (kg)250Max. Load (kg)250
Dumping Angle (˚)50 Dumping Angle (˚)50 Dumping Angle (˚)No dump function
Lifting Height (mm)1,390Lifting Height (mm)No lift functionLifting Height (mm)No lift function
Features and Performance
Lorry
Functions of dumping & lifting
With both functions of dumping & lifting, it reduces labor and improves productivity.
SB-3600ADL Lifting Height 1,390mm
Whether to drive a function of dumping of a lorry
SB-3600
SERIES
SB-3600ADLO
SB-3600ADO
SB-3600AX
Whether to drive a function of lifting of a lorry
SB-3600
SERIES
SB-3600ADLO
SB-3600ADX
SB-3600AX
The unique sliding function of a working table &
직선 자동 주행
With the unique sliding function of a working table, it considered convenience of an operator.
It increased work efficiency with a function of the automatic straight running.
A length of the extended working table of SB-3500 1,430mm
Whether to drive a function of the automatic straight running of a lorry
SB-3600
SERIES
SB-3600ADLO
SB-3600ADO
SB-3600AO
Whether to drive a sliding function of a working table
SB-3600
SERIES
SB-3600ADLX
SB-3600ADX
SB-3600AX
A video of product
